CRBH series cross roller bearing CRBH 20025-A UU

Ask Lasest Price
Model Number :	CRBH 20025-A UU
Price :	FOB
Delivery Time :	within one day
Payment Terms :	T/T In advance
Supply Ability :	5000PCS
Brand Name :	IKO

Add to Cart

Product Details
Company Profile

CRBH series cross roller bearing CRBH 20025-A UU

Specifications

CRBH series cross roller bearing

Type	Boundary dimensions (mm)			Basic rated loading		weight	equivalent
	Inner diameter	Outer diameter	Width	Radial (KN)		weight	equivalent
	d	D	B	C	Co	kg	IKO
CRBH2008	20	36	8	2.91	2.43	0.04	CCRBH2008
CRBH2508	25	41	8	3.12	2.81	0.05	CCRBH2508
CRBH3010	30	55	10	7.35	8.36	0.12	CCRBH3010
CRBH3510	35	60	10	7.9	9.13	0.13	CCRBH3510
CRBH4010	40	65	10	8.33	10.6	0.15	CCRBH4010
CRBH4510	45	70	10	8.86	11.3	0.16	CCRBH4510
CRBH5013	50	80	13	16.7	20.9	0.27	CCRBH5013
CRBH6013	60	90	13	18	24.3	0.3	CCRBH6013
CRBH7013	70	100	13	19.4	27.7	0.35	CCRBH7013
CRBH8016	80	120	16	30.1	42.1	0.7	CCRBH8016
CRBH9016	90	130	16	31.4	45.3	0.75	CCRBH9016
CRBH10020	100	150	20	33.1	50.9	1.45	CCRBH10020
CRBH11020	110	160	20	34	54	1.56	CCRBH11020
CRBH12025	120	180	25	66.9	100	2.62	CCRBH12025
CRBH13025	130	190	25	69.5	107	2.82	CCRBH13025
CRBH14025	140	200	25	74.8	121	2.96	CCRBH14025
CRBH15025	150	210	25	76.8	128	3.16	CCRBH15025
CRBH20025	200	260	25	84.2	157	4	CCRBH20025
CRBH25025	250	310	25	69.3	150	5	CCRBH25025

Note 1: nominal model with seal ring is CRBH***UU
Note 2: in the high-precision, please use the inner ring rotation way.

CRBH258 A, CRBH 258 A UU T1 Cross Roller Bearing belong to IKO Model CRBH series cross roller bearing(with separator). It's ultra-thin type, has integrated inner & outer ring, need housing and flange for fixing during installation.

Features:

CRBH series cross roller bearing has stable rotational precisioin and torque, suited for limited space, and where inner ring and outer ring rotation required.

A means open type, A UU means sealed on both sides.

Other CRBH cross roller bearing models

Open Type	Sealed Type	d (mm)	D (mm)	B (mm)	C (kN)	C0 (kN)	Mass (kg)
CRBH 208 A	CRBH 208 A UU	20	36	8	2.91	2.43	0.04
CRBH 258 A	CRBH 258 A UU	25	41	8	3.12	2.81	0.05
CRBH 3010 A	CRBH 3010 A UU	30	55	10	7.6	8.37	0.12
CRBH 3510 A	CRBH 3510 A UU	35	60	10	7.9	9.13	0.13
CRBH 4010 A	CRBH 4010 A UU	40	65	10	8.61	10.6	0.15
CRBH 4510 A	CRBH 4510 A UU	45	70	10	8.86	11.3	0.16
CRBH 5013 A	CRBH 5013 A UU	50	80	13	17.3	20.9	0.29
CRBH 6013 A	CRBH 6013 A UU	60	90	13	18.8	24.3	0.33
CRBH 7013 A	CRBH 7013 A UU	70	100	13	20.1	27.7	0.38
CRBH 8016 A	CRBH 8016 A UU	80	120	16	32.1	43.4	0.74
CRBH 9016 A	CRBH 9016 A UU	90	130	16	33.1	46.8	0.81
CRBH 10020 A	CRBH 10020 A UU	100	150	20	50.9	72.2	1.45
CRBH 11020 A	CRBH 11020 A UU	110	160	20	52.4	77.4	1.56
CRBH 12025 A	CRBH 12025 A UU	120	180	25	73.4	108	2.62
CRBH 13025 A	CRBH 13025 A UU	130	190	25	75.9	115	2.82
CRBH 14025 A	CRBH 14025 A UU	140	200	25	81.9	130	2.96
CRBH 15025 A	CRBH 15025 A UU	150	210	25	84.3	138	3.16
CRBH 20025 A	CRBH 20025 A UU	200	260	25	92.3	169	4
CRBH 25025 A	CRBH 25025 A UU	250	310	25	102	207	4.97

To learn more about our company or get the Installation Instructions of CRBH 258 A UU T1 crossed roller bearing regarding the installation size, weight, basic dynamic load rating, load, limiting speed, and clearance, please contact us. Drawing and sample of CRBH 258 A UU T1 crossed roller bearingare available upon request.
